BMX055 BOSCH 加速度+陀螺仪+地磁 9轴传感器

品牌:BOSCH 博世
型号:BMX055
规格:三轴12bit加速传感器+三轴16bit?±2000°/s+三轴地磁传感器

BMX055BMX055

Parameter Technical data
Resolution Accelerometer (A): 0.98 mg
Gyroscope (G): 0.004 °/s
Magnetometer: (M): 0.3 μT
Measurement ranges
(programmable)
(A): ±2g, ±4g, ±8g, ±16 g
(G): ±125°/s, ±250°/s,
±500°/s, ±1000°/s,
±2000°/s
(M): ±1200μT (x,y),
±2500μT (z)
Sensitivity
(calibrated)
(A): ±2g: 1024LSB/g
±4g: 512LSB/g
±8g: 256LSB/g
±16g: 128LSB/g
(G): ±125°/s: 262.4 LSB/°/s
±250°/s: 131.2 LSB/°/s
±500°/s: 65.6 LSB/°/s
±1000°/s: 32.8 LSB/°/s
±2000°/s: 16.4 LSB/°/s
(M): 3.3 LSB/μT
Zero point offset (A): ± 70mg (G): ± 1 °/s
(M): ± 10 μT
Noise density (typ.) (A): 150 μg/√Hz
(G): 0.014 °/s/√Hz
(M): 0.5 μT
Supply voltage (VDD) 2.4 … 3.6 V
I/0 supply voltage
(VDDIO)
1.2 … 3.6 V
Temperature range -40 … +85°C
Current consumption
(Gyro @ full operation)
5 mA
Current consumption
(Acc. @full operation)
130 μA
Current consumption
(Acc. @ wake-up
mode)
< 10 μA
Current consumption
(Magnet sensor @
10Hz ODR)
0.5 mA
Package dimensions 3 x 4.5 x 0.95mm3 (LGA)
Shock resistance 10,000 g x 200 μs
